The Right Choice for HMI Designs

RZ/A1 Embedded ARM® Microprocessors

The RZ Family of ARM-based High-Performance MPUs

Renesas RZ/A1 series microprocessors (MPUs) offer an innovative architecture based on the ARM Cortex®-A9 processor and up to an industry-leading 10MB of on-chip memory. RZ/A1 MPUs can execute code at 1000 DMIPS from the abundant on-chip memory or in-place from inexpensive QSPI memory, while using on-chip memory for graphics buffering up to WXGA (1280x800) resolution. The 128-bit wide internal memory bus with x4 parallel access enables higherthroughput memory access as compared to systems with external DDR memory. The RZ/A1 series offers enormous advantages in terms of BOM cost, performance, power consumption, and system design time, making it the right choice for HMI (Human Machine Interface) and other system-on-chip applications.

Features
Product Portfolio
Promotion Board
Development

Create Superior HMI Designs with Fewer Components

On-chip functions provided by RZ/A1 MPUs reduce BOM cost, save board space and minimize integration tasks. Typical applications like the one shown below take advantage of a rich portfolio of intellectual property from Renesas and can utilize a range of built-in peripherals, including: CMOS camera interface, JPEG Codec Unit, 12-bit ADC, and OpenVG 2D graphics engine, among others.

Build full-featured HMI solutions with digital audio and WXGA (1280x800) resolution using a single RZ/A1 MPU and SPI Flash

Features

Up to 10MB on-chip RAM

For code execution/data buffering

128-bit memory bus

With parallel (x4) access to deliver superior memory throughput

Execute-In-Place (XIP) from inexpensive QSPI memory

With three layers of cache

LCD controller to drive up to two independent WXGA displays

For vivid displays

Benefits

Lower BOM Cost

No external SDRAM or LCD controller
Simpler voltage regulators
Reduced PCB layers

Increased Performance

1000 DMIPS at 400MHz
6x throughput of 333MHz 16-bit DDR2

Decreased Power Consumption

Fewer board components
No copying of code from flash to RAM

Accelerate Time to Market

Simpler PCB design
Decreased EMI via reduced switching
No DDR procurement issues

RZ/A1L MPUs

Ideal Solutions for Cost-Sensitive Designs (up to WSVGA Resolutions)

Maximum 3 MB on-chip large-capacity RAM enables more compact system size
High-speed operation of CPU with maximum operating frequency of 400 MHz supports
Solutions fusing Renesas' experience and the ARM® ecosystem help shorten prototype

	Part Number	Description
RZ/A1L	R7S721020VCFP#AA1-ND	RZ/A1L 400MHZ 3MB QFP176 Q2A NO
	R7S721020VCBG#AC1-ND	RZ/A1-L MPU 3MB RAM 176BGA
	R7S721021VCFP#AA1-ND	RZ/A1L 400MHZ 3MB QFP208 Q2A NO

Renesas RZ/A1 Series Starter Kit

The Renesas Starter Kit+ for RZ/A1H has been developed to speed up device evaluation, code development, and reduce time to market. The Renesas Starter Kit+, as the name suggests, is a complete development kit for the Renesas RZ/A1H device family.

Renesas Starter Kit+ for RZ/A1H Package Contents

CPU board
TFT LCD option board
Detachable color LCD board PmodTM compatible
Detachable AD adjustment shaft
Segger J-LINK lite debugger
Connection cables (USB cable, user interface cable)
Multi-region power supply
Quick-start guide
DVD-ROM

Documents

User manual, tutorial, and more
e²studio IDE
KPIT GNU compiler for Cortex A9
Segger debugger drivers
Sample code

Speed Up Your Development With the RZ/A1 Ecosystem

Integrated Software Development Environments
	IAR Embedded Workbench® Integrated development environment and optimized C++ compiler for RZ MPUs Project management tools and editor Configuration files for all RZ devices Emulator debugger support Run-time libraries
	ARM The ARM DS-5™ Development Studio, Renesas RZ Edition, is a complete software development environment for systems that use RZ/A1 MPUs. This IDE provides the DS-5’s code editor, compiler, debugger and performance analyzer. These tools seamlessly generate, debug and optimize code for the powerful ARM Cortex-A9 CPU built into RZ/A1 series chips.
	Renesas e2 studio Based on the popular Eclipse open-source environment Complete IDE supports IAR and free GNU compilers Powerful project management Download free at: am.renesas.com/e2studio
	Green Hills Software Green Hills Software supports Renesas RZ/A1 MPUs with its MULTI® IDE, C/C++ optimizing compilers, Probe debugger, and many other development tools. These products let system engineers generate fast, compact code, quickly find and fix bugs, and make sense of complex systems.
