782482 Series

782482 Series ADM2482E/ADM2487E Compatible Converter Transformers

Murata Power Solutions Inc

This tutorial will introduce and review the 782482 series transformers, one of two supplier parts approved for use with Analog Devices high speed transceivers.  Applications include isolated RS-485/RS-422 interfaces, industrial field networks and multipoint data transmission systems.

Related Parts

ImageManufacturer Part NumberDescriptionET (Volt-Time)Turns Ratio - Primary:SecondaryAvailable QuantityPriceView Details
XFRMR CONV ADM2482 5.0V IN782482/53VCXFRMR CONV ADM2482 5.0V IN-1.14CT:1CT1436 - Immediate$1.80View Details
XFRMR CONV ADM2482 3.3V IN782482/33VCXFRMR CONV ADM2482 3.3V IN-1CT:1.33CT0 - Immediate$1.80View Details
PTM Published on: 2011-06-02

Related Videos

782482 Series Transformer
782482 Series Transformer

Publish Date: 2022-07-27

Related Product Highlight

782482 Series Converter Transformers Murata Power Solutions' 782482 series of converter transformers are specifically designed for use with Analog Devices chipsets.
