TX2 Series
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
TX2 Series
TX-PC

TX2-12V

Digi-Key Part Number
255-1032-5-ND
Manufacturer
Panasonic Electric Works
Manufacturer Product Number
TX2-12V
Description
RELAY TELECOM DPDT 2A 12V
Manufacturer Standard Lead Time
24 Weeks
Detailed Description
Telecom Relay DPDT (2 Form C) Through Hole
Customer Reference
Datasheet Datasheet
Product Attributes
Type
Description
Select
Category
Mfr
Panasonic Electric Works
Series
TX
Package
Tube
Product Status
Active
Mounting Type
Through Hole
Coil Voltage
12VDC
Contact Form
DPDT (2 Form C)
Contact Rating (Current)
2 A
Switching Voltage
220VDC - Max
Coil Current
11.7 mA
Coil Type
Non Latching
Features
-
Termination Style
PC Pin
Seal Rating
Sealed - Fully
Coil Insulation
-
Must Operate Voltage
9 VDC
Must Release Voltage
1.2 VDC
Operate Time
4 ms
Release Time
4 ms
Operating Temperature
-40°C ~ 85°C
Contact Material
Silver (Ag), Gold (Au)
Relay Type
Telecom
Coil Resistance
1.03 kOhms
Base Product Number
TX2-12
Documents & Media
Resource TypeLink
DatasheetsTX2 Series Relay Datasheet
Other Related Documents
Video File
How to Choose a Relay - Another Teaching Moment
Relay Basics - Another Teaching Moment | DigiKey Electronics
PCN PackagingMult Dev Label Chgs 20/Sep/2019
HTML DatasheetTX2 Series Relay Datasheet
EDA ModelsTX2-12V by Ultra Librarian
Product Drawings
ManualsT-Series Relays, Cautions for Use
Environmental & Export Classifications
AttributeDescription
RoHS StatusRoHS Compliant
Moisture Sensitivity Level (MSL)1 (Unlimited)
ECCNEAR99
HTSUS8536.41.0020
26 533 In Stock
All prices are in EUR
Tube
QtyUnit PriceExt Price
12,01000 €2,01 €
251,67120 €41,78 €
1001,50400 €150,40 €
5001,25330 €626,65 €
5 0001,12797 €5 639,85 €
You May Also Be Interested InSee All 15
Additional Resources
AttributeDescription
Other Names
TX212V
255-1032-5
ATX203
255-1032-ND
255-1032-NDL
255-1032
Q1255549
Standard Package40
