Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
0022288023 | ||
|---|---|---|
Digi-Key Part Number | WM50026-02-ND | |
Manufacturer | ||
Manufacturer Product Number | 0022288023 | |
Description | CONN HEADER R/A 2POS 2.54MM | |
Detailed Description | Connector Header Through Hole, Right Angle 2 position 0.100" (2.54mm) | |
Customer Reference | ||
Datasheet | Datasheet | |
EDA/CAD Models | 0022288023 Models | |
Product Attributes
Type | Description | Select All |
|---|---|---|
Category | ||
Mfr | ||
Series | ||
Package | Bulk | |
Product Status | Active | |
Connector Type | ||
Contact Type | Male Pin | |
Pitch - Mating | ||
Number of Positions | ||
Number of Rows | 1 | |
Row Spacing - Mating | - | |
Number of Positions Loaded | All | |
Style | ||
Shrouding | Unshrouded | |
Mounting Type | ||
Termination | Solder | |
Fastening Type | Push-Pull | |
Contact Length - Mating | 0.324" (8.23mm) | |
Contact Length - Post | 0.120" (3.05mm) | |
Overall Contact Length | - | |
Insulation Height | 0.098" (2.50mm) | |
Contact Shape | Square | |
Contact Finish - Mating | Gold | |
Contact Finish Thickness - Mating | 15.0µin (0.38µm) | |
Contact Finish - Post | Tin | |
Contact Material | - | |
Insulation Material | Polyamide (PA), Nylon, Glass Filled | |
Features | - | |
Operating Temperature | - | |
Ingress Protection | - | |
Material Flammability Rating | UL94 V-0 | |
Insulation Color | Black | |
Current Rating (Amps) | - | |
Voltage Rating | - | |
Mated Stacking Heights | - | |
Contact Finish Thickness - Post | 100.0µin (2.54µm) | |
Applications | Automotive, General Purpose, Medical, Telecommunications | |
Base Product Number |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheets | |
| Environmental Information | 0022288023 RoHS Cert of Compliance |
| Featured Product | |
| CAD Models | 0022288023 Models |
| PCN Assembly/Origin | Mult Devs Supplier 09/Dec/2022 |
| HTML Datasheet | |
| 3D Drawings | 22-28-8023.pdf |
| Product Drawings |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8536.69.4040 |
Quantity
All prices are in EUR
Bulk
| Qty | Unit Price | Ext Price |
|---|---|---|
| 1 | 0,20000 € | 0,20 € |
| 10 | 0,15700 € | 1,57 € |
| 100 | 0,11310 € | 11,31 € |
| 1 000 | 0,08844 € | 88,44 € |
| 5 000 | 0,07862 € | 393,10 € |
| 10 000 | 0,07125 € | 712,50 € |
Manufacturers Standard Package
Alternate Length
CONN HEADER R/A 3POS 2.54MM Total Quantity 443 |
CONN HEADER R/A 4POS 2.54MM Total Quantity 1 154 |
CONN HEADER R/A 5POS 2.54MM Total Quantity 1 021 |
CONN HEADER R/A 6POS 2.54MM Total Quantity 1 107 |
CONN HEADER R/A 7POS 2.54MM Total Quantity 1 465 |
CONN HEADER R/A 8POS 2.54MM Total Quantity 1 026 |
CONN HEADER R/A 9POS 2.54MM Total Quantity 0 |
CONN HEADER R/A 10POS 2.54MM Total Quantity 618 |
CONN HEADER R/A 11POS 2.54MM Total Quantity 0 |
CONN HEADER R/A 12POS 2.54MM Total Quantity 0 |
CONN HEADER R/A 13POS 2.54MM Total Quantity 0 |
CONN HEADER R/A 14POS 2.54MM Total Quantity 0 |
CONN HEADER R/A 15POS 2.54MM Total Quantity 0 |
CONN HEADER R/A 16POS 2.54MM Total Quantity 0 |
CONN HEADER R/A 17POS 2.54MM Total Quantity 0 |
CONN HEADER R/A 18POS 2.54MM Total Quantity 0 |
CONN HEADER R/A 19POS 2.54MM Total Quantity 0 |
CONN HEADER R/A 20POS 2.54MM Total Quantity 0 |
CONN HEADER R/A 21POS 2.54MM Total Quantity 0 |
CONN HEADER R/A 22POS 2.54MM Total Quantity 0 |
Additional Resources
| Attribute | Description |
|---|---|
| Other Names | 22-28-8023-ND WM6302-ND 22-28-8023-E 0022288023 0022-28-8023 22-28-8023 WM6302 WM50026-02 0022-28-8023-E 22288023 0022288023-E 22288023-E |
| Standard Package | 1 |
