MDSM-10R-20-25 | ||
|---|---|---|
Digi-Key Part Number | HE564TR-ND - Tape & Reel (TR) HE564CT-ND - Cut Tape (CT) HE564DKR-ND - Digi-Reel® | |
Manufacturer | ||
Manufacturer Product Number | MDSM-10R-20-25 | |
Description | SWITCH REED SPST-NO 350MA 140V | |
Manufacturer Standard Lead Time | 17 Weeks | |
Detailed Description | Glass Body Reed Switch SPST-NO 20 ~ 25AT Operate Range 10W 350mA (AC), 500mA (DC) 140 V Surface Mount | |
Customer Reference | ||
Datasheet | Datasheet | |
Product Attributes
Type | Description | Select All |
|---|---|---|
Category | ||
Mfr | Littelfuse Inc. | |
Series | ||
Package | Tape & Reel (TR) Cut Tape (CT) Digi-Reel® | |
Product Status | Active | |
Type | Glass Body Reed | |
Circuit | SPST-NO | |
Operate Range | 20 ~ 25AT | |
Release Range | - | |
Current - Switching | 350mA (AC), 500mA (DC) | |
Voltage - Switching AC | 140 V | |
Voltage - Switching DC | 200 V | |
Power - Rated | 10W | |
Operate Time | 0.5 ms | |
Release Time | 0.1 ms | |
Mounting Type | Surface Mount | |
Termination Style | Gull Wing | |
Length - Overall | 0.615" (15.62mm) | |
Size - Body | 0.071" Dia x 0.400" L (1.80mm x 10.16mm) | |
Height Above Board | 0.079" (2.00mm) | |
Operating Temperature | -40°C ~ 125°C | |
Capacitance | 0.2 pF | |
Current - Carry | 1A (DC) |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheets | |
| Environmental Information | RoHS 3 Cert MDSM-10R-20-25 |
| HTML Datasheet | |
| Product Drawings |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8536.50.9065 |
| California Prop 65 |  Warning Information |
