6-DIP Pkg
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

4N25

Digi-Key Part Number
160-1300-5-ND
Manufacturer
Lite-On Inc.
Manufacturer Product Number
4N25
Description
OPTOISO 2.5KV TRANS W/BASE 6DIP
Manufacturer Standard Lead Time
12 Weeks
Detailed Description
Optoisolator Transistor with Base Output 2500Vrms 1 Channel 6-DIP
Customer Reference
Datasheet Datasheet
Product Attributes
Type
Description
Select All
Category
Mfr
Lite-On Inc.
Series
4N2X
Package
Tube
Product Status
Active
Number of Channels
1
Voltage - Isolation
2500Vrms
Current Transfer Ratio (Min)
20% @ 10mA
Current Transfer Ratio (Max)
-
Turn On / Turn Off Time (Typ)
-
Rise / Fall Time (Typ)
3µs, 3µs
Input Type
DC
Output Type
Transistor with Base
Voltage - Output (Max)
30V
Current - Output / Channel
100mA
Voltage - Forward (Vf) (Typ)
1.2V
Current - DC Forward (If) (Max)
80 mA
Vce Saturation (Max)
500mV
Operating Temperature
-55°C ~ 100°C
Mounting Type
Through Hole
Package / Case
6-DIP (0.300", 7.62mm)
Supplier Device Package
6-DIP
Base Product Number
4N25
Documents & Media
Resource TypeLink
Datasheets4N25, 4N26 Series
HTML Datasheet4N25, 4N26 Series
EDA Models
Product DrawingsOptoisolator Circuit
Environmental & Export Classifications
AttributeDescription
RoHS StatusROHS3 Compliant
Moisture Sensitivity Level (MSL)1 (Unlimited)
ECCNEAR99
HTSUS8541.49.8000
2 952 In Stock
All prices are in EUR
Tube
QtyUnit PriceExt Price
10,41000 €0,41 €
1000,14440 €14,44 €
1 0000,11605 €116,05 €
5 0000,09671 €483,55 €
25 0000,08704 €2 176,00 €
100 0000,08123 €8 123,00 €
You May Also Be Interested InSee All 16
Additional Resources
AttributeDescription
Other Names160-1300-5
Standard Package65
