TL3301AF160QJ
Description
SWITCH TACTILE SPST-NO 0.05A 12V
Manufacturer Standard Lead Time
14 Weeks
Detailed Description
Tactile Switch SPST-NO Top Actuated Surface Mount
Customer Reference
Datasheet
 Datasheet
EDA/CAD Models
TL3301AF160QJ Models
Product Attributes
Type
Description
Select All
Category
Mfr
E-Switch
Series
TL3301
Package
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
Product Status
Active
Circuit
SPST-NO
Switch Function
Off-Mom
Contact Rating @ Voltage
0.05A @ 12VDC
Actuator Type
Standard
Mounting Type
Surface Mount
Actuator Height off PCB, Vertical
5.00mm
Actuator Length, Right Angle
-
Actuator Orientation
Top Actuated
Termination Style
J Lead
Outline
6.00mm x 6.00mm
Illumination
Non-Illuminated
Illumination Type, Color
-
Illumination Voltage (Nominal)
-
Operating Force
160gf
Ingress Protection
-
Features
-
Operating Temperature
-20°C ~ 70°C
Actuator Material
Polyamide (PA), Nylon
Switch Travel
0.25mm
Mechanical Life
100,000 Cycles
Base Product Number
TL3301
Documents & Media
Resource TypeLink
Datasheets
Product Training Modules
Video File
Additional Requirements for Selecting a Switch
E-Bits – TL3301 – SMD Tactile Switches
What Switch do You Need?
Environmental InformationE-Switch RoHS 3 Cert
Featured ProductTL3301 Series Tact Switch
CAD ModelsTL3301AF160QJ Models
HTML DatasheetTL3301AF160QJ Drawing
EDA ModelsTL3301AF160QJ Models
Product DrawingsTL3301AF Footprint
Environmental & Export Classifications
AttributeDescription
RoHS StatusROHS3 Compliant
Moisture Sensitivity Level (MSL)1 (Unlimited)
REACH StatusREACH Unaffected
ECCNEAR99
HTSUS8536.50.9031
Quantity
All prices are in EUR
Cut Tape (CT) & Digi-Reel®
QtyUnit PriceExt Price
10,42000 €0,42 €
100,40800 €4,08 €
250,39280 €9,82 €
1000,33980 €33,98 €
2500,30956 €77,39 €
5000,28694 €143,47 €
* All Digi-Reel orders will add a 5,50 € reeling fee.
Tape & Reel (TR)
QtyUnit PriceExt Price
1 1000,25673 €282,40 €
3 3000,24313 €802,33 €
5 5000,22501 €1 237,55 €
11 0000,20991 €2 309,01 €
Manufacturers Standard Package
You May Also Be Interested InSee All 19
Additional Resources
AttributeDescription
Other Names
P010508
EG4374TR
EG4374DKR
EG4374CT
Standard Package1 100
