ABLSG-14.7456MHZ-D2Y-T | ||
|---|---|---|
Digi-Key Part Number | 535-10614-2-ND - Tape & Reel (TR) 535-10614-1-ND - Cut Tape (CT) 535-10614-6-ND - Digi-Reel® | |
Manufacturer | ||
Manufacturer Product Number | ABLSG-14.7456MHZ-D2Y-T | |
Description | CRYSTAL 14.7456MHZ 18PF SMD | |
Manufacturer Standard Lead Time | 25 Weeks | |
Detailed Description | 14.7456 MHz ±20ppm Crystal 18pF 50 Ohms HC-49/US - 3 Lead | |
| Customer Reference | ||
| Datasheet | Datasheet | |
Product Attributes
Type | Description | Select All |
|---|---|---|
Category | ||
Mfr | ||
Series | ||
Package | Tape & Reel (TR) Cut Tape (CT) Digi-Reel® | |
Product Status | Active | |
Type | MHz Crystal | |
Frequency | 14.7456 MHz | |
Frequency Stability | ±30ppm | |
Frequency Tolerance | ±20ppm | |
Load Capacitance | 18pF | |
ESR (Equivalent Series Resistance) | 50 Ohms | |
Operating Mode | Fundamental | |
Operating Temperature | -40°C ~ 85°C | |
Ratings | - | |
Mounting Type | Surface Mount | |
Package / Case | ||
Size / Dimension | 0.449" L x 0.185" W (11.40mm x 4.70mm) | |
Height - Seated (Max) | 0.165" (4.20mm) |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheets | ABLSG Series Datasheet |
| Video File | Abracon: Who We Are Today |
| Environmental Information | Abracon REACH |
| HTML Datasheet | |
| EDA Models | ABLSG-14.7456MHZ-D2Y-T by SnapEDA |
| 3D Drawings | ABLSG.pdf |
| Product Drawings |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | Not Applicable |
| REACH Status | REACH Affected |
| ECCN | EAR99 |
| HTSUS | 8541.60.0050 |
